Woven Fiberglass Prepreg
Woven glass-fiber reinforcement supplied with a pre-impregnated resin matrix. Choose plain or twill construction, dry fabric weight and resin content for your molding process.
Series image. Confirm the exact construction and specification with your sample.
Choose your specification
Woven glass-fiber reinforcement supplied with a pre-impregnated resin matrix. Choose plain or twill construction, dry fabric weight and resin content for your molding process.
- Plain or twill reinforcement
- Dry glass-fabric weight and resin content
- Finished width, resin system and molding process
- Required cure schedule, storage conditions and technical data
Configuration options
| Weave | Dry fabric weight | Resin content | Reference width |
|---|---|---|---|
| Plain | 100 g/m² | 38% | 1000–1270 mm |
| Plain | 185 g/m² | 38% | 1000–1270 mm |
| Twill | 210 g/m² | 38% | 1000–1270 mm |
| Twill | 220 g/m² | 40% | 1000–1270 mm |
Dry fabric weight refers to the glass reinforcement, not the total prepreg weight. Confirm the resin system, cure cycle and storage requirements for the selected material.
Configuration options are a starting point for selection. Confirm the exact specification and technical data sheet with your quotation.
